Briggs & Stratton 40684 10KW Power Protect Standby Generator 6 Year Warranty
Overview
The 10kW Fortress standby generator provides your family with peace of mind during a power outage with a smaller, sleeker generator. Although small, it still packs plenty of power so your home's basic circuits and small appliances stay on during an outage.
Features
|
|
|
|
|
|
1 This generator is rated in accordance with UL (Underwriters Laboratories) 2200 (stationary engine generator assemblies) and CSA (Canadian Standards Association) standard C22.2 No.100-14 (motors and generators).
2 See operator's manual for complete warranty details.
3 Installations must strictly comply with all applicable codes, industry standards, laws, regulations and provided installation manual. Running engines give off carbon monoxide, an odorless, colorless, poisonous gas so it is important to keep exhaust gas away from any windows, doors, ventilation intakes or crawl spaces. The installation manual contains specific instructions related to generator placement in addition to NFPA 37, including the requirement that carbon monoxide detectors be installed and maintained in your home or business.
Specifications
Model | 040684 |
Running kW (LP)* | 10 |
Running kW (NG)* | 9 |
Running Amps (LP)* | 41.7 |
Running Amps (NG)* | 37.5 |
Engine | Vanguard |
Phase | 1-Phase |
Circuit Breaker Amps | 50 |
Frequency (Hz) | 60 |
Engine Displacement (cc) | 570 |
Voltage (V) | 120/240 |
Enclosure Materials | Steel Base & Aluminum Enclosure |
Sound Level (dBA) at 7 Meters | 67 |
NG Fuel Consumption at 50% Load**( BTU/hr) | 111,000 |
LP Fuel Consumption at 50% Load** (BTU/hr) | 107,000 |
Length (in) | 38.5 |
Width (in) | 33 |
Height (in) | 42.5 |
Weight (lbs) | 331 |
Warranty (Product)*** | 6 Years Parts, Labour, & Travel Warranty |
Weekly Exerciser | Yes |
Battery Charger | Yes |
*NG = Natural Gas; LP = Liquid Propane.
**Fuel consumption rates are estimated based on normal operating conditions. Generator operation may be greatly affected by elevation and the cycling operation of multiple electrical appliances - fuel flow rates may vary depending on these factors.
***See Operator's Manual for complete warranty details.
